5 Years Warranty | IP66 | DC12V | High Efficiency 130lm/W
Designed for hazardous environments, providing safe and reliable illumination for Zone 2 and Zone 22 explosive gas and dust atmospheres.
The linear Ex light fitting type BHD51 is intended for use in places with an explosive gas and dust atmosphere. It is designed for industrial facilities, both indoor and outdoor.
| Parameter | Value (unit) |
|---|---|
| Supply voltage | 100-240VAC 50/60Hz |
| Apparatus category | II 3GD |
| ATEX marking (Zone 2) | II3G Ex nR IIC T6 Gc |
| ATEX marking (Zone 22) | II 3D Ex tc IIIC T80 ºC Dc IP66 |
| Ingress protection | IP 66 |
| Resistance to shock | IK09 |
| Light source | Luxeon & Cree SMD3030 |
| Estimated service life | 70,000h at Tamb=40°C |
Housing: High light transmittance PC material, impact strength > 4J.
Diffuser: Polycarbonate (PC) plastic.
Gasket: Nitrile rubber with excellent aging and corrosion resistance.
Light Shell: High-pressure die-casting aluminum alloy for superior hardness.
Fasteners: STS304 stainless steel for high anti-corrosion performance.
| MODEL WATTAGE | 10/20W | 40W | 60W |
|---|---|---|---|
| LUMEN OUTPUT | 1300-2400 LM | 4800 LM | 7200 LM |
| DIMENSIONS (mm) | 720 x 113 x 125 | 1020 x 113 x 125 | 1320 x 113 x 125 |
| NET WEIGHT | 3.4 kg | 3.8 kg | 4.2 kg |
| ENCLOSURE | Copper free aluminum alloy and PC pipe | ||
| CRI | > 80 | ||
| EFFICIENCY | 120 LPW | ||
| SURGE PROTECTION | 4 kV | ||
| WARRANTY | 5 Years | ||
